M 3 PR M 3 PRT M 3 PRTS M 3 PRTSG

SUMMARY

Pages Description Type

6 Engine Unit - set of engine gaskets M3PR - M3PRT - M3PRTS - M3PRTSG

7 Engine Swivelling attachment - exhaust M3PR - M3PRT - M3PRTS - M3PRTSG
8 Engine exploded M3PR - M3PRT - M3PRTS

9 Engine exp/oded M3PRTSG
10 Piston matching M3PR - M3PRT - M3PRTS - M3PRTSG
11 Clutch M3PR - M3PRT - M3PRTS - M3PRTSG

12 Carburetor complete GU RTNE R AR J J 1.5 adjusting M3PR - M3PRT - M3PRTS - M3PRTSG
13 Flywhee/ magneto 8 W M3PR - M3PRT - M3PRTS - M3PRTSG

14 Pulley - pedal unit - chains - chain tensioner M3PR - M3PRT - M3PRTS - M3PRTSG
...
15 Telescopic fork M3PRT - M3PRTS - M3PRTSG
16 Frame - centre stand - mudguard - luggage carrier M3PR - M3PRT

17 Frame - centre stand - oscilating arm M3PRTS - M3PRTSG
18 Fork - steering head races - front brake M3PR

19 Saddle - shock absorber M3PR - M3PRT - M3PRTS - M3PRTSG
20 Front whee/ and hub M3PR
21 Front wheel and hub LELEU 70 M3PRT - M3PRTS - M3PRTSG

22 Rear whee/ and hub LELEU 70 M3PR - M3PRT
23 Rear wheel and hub LELEU 70 M3PRTS - M3PRTSG

24 Grips and controls M3PR - M3PRT - M3PRTS - M3PRTSG
25 Handlebars - attachment M3PR - M3PRT - M3PRTS - M3PRTSG
26 Head/amp - tail /amp - horn wiring and speedometer M3PR - lV3PRT - M3PRTS - M3PRTSG

27 Legshield - attachment - front luggage carrier M3PR
30-31 Numerica/ index

5
